Product Description
Model: AM05
Features & functions:
Multi-function 7″ 1080P HD mini under vehicle inspection camera DVR system
HD 1080P 3.5 Mega digital camera.
Φ18mm mini camera with 6 IR/LED night vision.
Waterproof Rate IP68.
Support 64GB TF card.
Support HDMI video output.
Support H.264 Video Compression Format.
5000mah li-battery, 10 hours working time.
2m Telescopic Survey Pole for all-purpose usage.
Excellent video and photo as iphone
Application:
Home Inspection: Roof, gutter, chimney,Loft and Attic, Basement Inspection.
Wildlife Survey: bird’s nest, snake’s cave,fish pond, pet house, aquarium,aqualculture monitor
Construction Inspection:tunnel and manhole ,well, elevator shaft, track drill, mine, riverbed
Under Vehicle detection: cars, truck,excavator,SUV and so on.
Under Boat/yacht Inspection and floating resort monitor.
Extend your hand and eye for checking everywhere.
specification:
| Mini camera | Optical Element | 1/3 CMOS Sensor |
| Optical Total Pixels | 3.0 Mega:2304(H)×1536(V) | |
| CMOS Sensor Size | 5.07mm(H)×3.38mm(V) | |
| Sensitivity | 0.2Lux/F1.2 | |
| Led lamp | 6pcs 8lm/pcs controlled on DVR | |
| Lens & View angle | 0.5mm F1.2 90 ° | |
| HD Video Output Interface | FPD-LinkIII | |
| Waterproof rate | IP68 | |
| Dimension | 18 x 28mm | |
| Cable(5 Cores High-Speed Line) | Diameter:3.5mm Length:6m | |
| Pole style | telescopic pole | |
| Pole length & Weight | 5m 0.9kg | |
|
7 inch Monitor |
HD Video Output | HDMI:1920* 1080;1280*720 |
| Video Storage Pixels(16:9) | HDMI:1920* 1080;1280*720 | |
| Video Compression Format | H.264 | |
| Video Storage | AVI | |
| HD Digital Video Input Interface | FPD-LinkIII | |
| Audio Frequency Range | 20HZ-20KHz AAC | |
| Audio Compression Format | AAC | |
| Photo Format | JPG 3.15 Mega :3200(H)×1800(V) | |
| Storage External SD card | TF card 1GB-64GB(Optional) | |
| 64GB recording time | 10-32 hours | |
| Operating System | Windows & Mac OS | |
| Ports | USB 2.0/AV-OUT | |
| Language | Multiple | |
| Voltage | DC :7-24V USB DC:5V | |
| Current(Monitor mode) | 600MA | |
| Current(Video mode) | 700MA | |
| AC Adapter | DC 12V 2A | |
| Built-in Battery | Li-battery 5000Mah | |
| Record time | ≥10hours | |
| Dimension: | 177mm x120mm x 20mm | |
| Weight | 350g |
Package contents
Mini camerax1
7inch DVRx1
AC Adpater
Manualx1
