Product Description
Product Introduction
1) Precision motor-driven, responsive, smoothly operation, the precision deviation less than 0.1 degree.
2) AHD1080P with 10x optical zoom
3) Support lightning protection, anti-surge, anti-surge function.
4) Outside weather-proof level up to IP66
5) Support mobile phone Android, iPhone OS view app:cloudlens
6)Support OSD, 3D function
7) 4.5″ metal material
Features
1)6 PCS high-power infrared lights, no flashlight effect , IR distance 40-80 m.
2)360°endless pan range and 0°- 93°tilt range, support auto-flip, non-surveillance blind area
3)Max. pan preset speed of 200°/s and max. tilt preset speed of 30°/s
4)Pan keyboard speed 0.6°~180°/s, tilt keyboard speed 3.5°~30°/s.
5)Support 220 preset, support 3 patrols, each patrol can contain up to 16 presets;
6)Support 4 patterns, can totally record up to 1 minus.
7)Support scan between two presets, area limited.
Details
Specification
Effective Pixels:
AHD1080P high speed camera
Min. Illumination:
Color: 0.2Lux(F1.6, AGC ON),
B/W: 0.01Lux(F1.6, AGC ON)
White Balance:
Auto
AGC:
Auto/Manual
S/N Ratio:
>50dB
Day & Night:
yes
Backlight Compensation:
support
Digital Noise Reduction:
3D DNR
Wide Dynamic Range:
support
Shutter Speed:
1/10s-1//10,000s
Focus Mode:
Auto/Manual/ONEAF
Lens
Focal Length:
10X optical zoom,day vision 500m
Zoom Speed:
Approx.3.5s(Optical Wide-Tele)
Angle of View:
H: 47°(W)~5.3°(T) V:35.6°(W)~3.96°(T)
Min. Working Distance:
10mm ~ 1,000mm (Wide-Tele)
Aperture Range:
F1.6 ~ F 2.8
Pan/Tilt
Pan / Tilt Range:
Pan: 360° endless; Tilt: -0° ~ 93° (Auto-Flip)
Pan / Tilt Speed:
Pan Speed: 0.6° ~ 200° /s,Tilt Speed: 3.5° ~ 50° /s
Proportional Zoom:
support
Number of Preset:
220
Patrol:
3 patrols, up to 16 presets per patrol
Park Action:
Pattern / Pan Scan / Tilt scan / Random scan / Frame scan
Network
Ethernet:
10Base-T/100Base-TX, RJ45 connector
Max. Image Resolution:
1920×1080
Frame Rate:
60HZ:30fps(1920×1080) 60HZ:30fps(1280×1080)
Image Compression:
H.264/MJPEG
Simultaneous Live View:
Up to 6
Streams:
Dual Streams
User/Host Level:
Up to 32 users,3 Levels: Administrator, Camera control,
Live view only
Security Measures:
User authentication (ID and PW)
Host authentication (MAC address)
Integration
Application programming:
Open-ended API, support Onvif, PSIA and CGI
General
IR distance:
40m-80m
RS-485 Protocols:
Pelco-P, Pelco-D, self-adaptive
Working Temperature:
12VDC: -20°C~60°C
Humidity:
90% or less
Protection Level:
TVS3000V lightning protection, surge protection and
voltage transient protection, weather proof: IP66
Package Dimension:
265*250*210mm
Weight (approx.):
2.28Kg
Camera Weight:
1.47kg
Mount Option:
Wall mount,
Power:
DC12V/2A
Horizontal 360 degree Vertical 93 degree All Direction Monitor
Package
1 x ptz dome camera
1 x power plug
1 x accessory
1 x user manual
