Portable rechargeable lithium polymer battery 5v 20ah//9V 12A/12V 9.8Ah 3 in 1 for Phone and CCTV Camera
Portable rechargeable lithium polymer battery 5v 20ah//9V 12A/12V 9.8Ah 3 in 1 for Phone and CCTV CameraPortable rechargeable lithium polymer battery 5v 20ah//9V 12A/12V 9.8Ah 3 in 1 for Phone and CCTV CameraPortable rechargeable lithium polymer battery 5v 20ah//9V 12A/12V 9.8Ah 3 in 1 for Phone and CCTV CameraPortable rechargeable lithium polymer battery 5v 20ah//9V 12A/12V 9.8Ah 3 in 1 for Phone and CCTV CameraPortable rechargeable lithium polymer battery 5v 20ah//9V 12A/12V 9.8Ah 3 in 1 for Phone and CCTV Camera

Portable rechargeable lithium polymer battery 5v 20ah//9V 12A/12V 9.8Ah 3 in 1 for Phone and CCTV Camera

designing and assembling custom battery solutions in all chemistries and for all electronic applications.

Product Description



Portable rechargeable lithium polymer battery 5v 20ah//9V 12A/12V 9.8Ah 3 in 1 for Phone and CCTV Camera Portable rechargeable lithium polymer battery 5v 20ah//9V 12A/12V 9.8Ah 3 in 1 for Phone and CCTV Camera Portable rechargeable lithium polymer battery 5v 20ah//9V 12A/12V 9.8Ah 3 in 1 for Phone and CCTV Camera Portable rechargeable lithium polymer battery 5v 20ah//9V 12A/12V 9.8Ah 3 in 1 for Phone and CCTV Camera Portable rechargeable lithium polymer battery 5v 20ah//9V 12A/12V 9.8Ah 3 in 1 for Phone and CCTV Camera Portable rechargeable lithium polymer battery 5v 20ah//9V 12A/12V 9.8Ah 3 in 1 for Phone and CCTV Camera

Portable rechargeable lithium polymer battery 5v 20ah//9V 12A/12V 9.8Ah 3 in 1 for Phone and CCTV Camera

Product Description

Specification:
1) Input voltage: 12.6V DC

2) Out voltage: 12.6V~10.8V DC

3) Battery capacity: 9800mAh 12V/9V 12000mAh/5V 20000mAh

4) Battery Size: 125*72*30mm

5) Battery Weight: 360g

6) One Kit Package weight:480g.

Model
YSD-998
Product Type
Lithium ion batteries
Nominal voltage
11.1V
Capacity
Custom
Input
12.6V
Dimension
Custom
Output
12.6-10.8V
Max continuous charge/discharge current
2.5A(Adjustable)
Battery cells
A grade batetry cells
PCM
12V A grade PCM,over-charge/discharge protection, over-heat protection
LED Indicator
Available
ON/OFF Switch
Available
Connectors
5.5*2.1mm DC jack+5.5*2.1mm DC plug
Recharge cycle
More than 500 times
Battery Charger
12.6V US/EU/UK plug
Charging full time
Around 5 hours
Operating temperature
-20 °C to 60 °C
Charge temperature
-0 °C to 45 °C
Storage temperature
-20 °C to 45 °C
Operating humidity
5% to 90%,non-condensing

12V lithium ion battery application:
LED strip/panel,Camera/IP Camera
Car camera recorder
Router/Switch
POS machine
Solar energy storage
Speaker and so on

12V lithium ion battery certificate and warranty:
CE, CB(UL), EC, MSDS and so on
One year

Payment:
T/T, paypal, and Western Union,Money gram.



Type of Packing: Color Box

Packaging Size(cm) PCS/CTN
17.5*12*3.5CM 20
Carton Size(cm) N.W.(kg) G.W.(kg)
37*26*23CM 9.8 10

Shipping: DHL,Fedex,UPS,TNT,Aramex,SF-express,Air transportation,etc
Package Includes: Travel Charger

We will send the correct Plug Adapter that suitable for the Country in the shipping address:

Europe Plug Adapter (2 Pin Round Pin):
Europe countries, Africa, Middle East

USA Plug Adapter (2 Pin Flat Pin):
United States, South America, Caribbean, Canada, Japan, Korea, Philippines, Thailand and Taiwan

Australia/New Zealand 2 Pin Plug Adapter:
Australia, New Zealand, Argentina

UK Plug Adapter (3 Pin Flat Pin):
England, Ireland, Scotland, Hong Kong, Pakistan, Singapore, Malaysia, Vietnam, Maldives and Qatar

Pacakge Includes:

1 x 12V Super Rechargeable Li-ion Battery
1 x Charger (EU/US Plug,option)
Warning:
To reduce the risk of fire or burns.
<1>. Do not attempt to open,disassemable,or service the battery pack
<2>. Do not crush,puncture,short external contacts of dispose of in fire or water above 60 Degree
Instruction:

1.turn on the switch on the battery,the red indicator on the battery will be on.
2.The charger adapter has a indicator on the charger.when you connect the charger with AC power,and the battery connect with the battery,the red indicator will be on on the charger adapter.

In a word.AC Power connect with DC the charger,the Charger connect with the battery,turn on the switch on the battery.then it start to charge for your battery.

4.when the red indicator of the charger adapter turn to green,then the battery is fully charged.
it only need 6-8 hours to charge fully.

5.the indicator on the battery,it will always red.when the power of the battery use out,it will turn dark,though it has nearly 5% power,the red indicator will still on.

To charge
Switch on the adapter and the red light would be on ,press the switch of the battery to “ON”and the indicator would be on.

Connect the point of the adapter to “DC In/Out”of the battery and the green light would be on,which indicates it starts to charge,the box does not finish charging unit the green light is off.(the charging times lasts at least 8 hours)

To supply
Connect one point of the power wire to “DC In/out”of the battery and press the switch to “ON” and the other point of the power wire to any kinds of household appliances with the special technology,the inner circuit cut off
Automatically in case of incorrectly use,resulting in no output.but you can renew its output so long as to recharging battery.

Caution
Do use the specialized accessory to recharge.the input voltage of any appliance must be in the range of the output of the battery,otherwise it can do harm to appliance.
To avoid the descending capacity, the battery must not be put away over 1 year.
Away from high temperature,and kept in cool dry place.
