Product Description
M12/CS mounted IR-Cut Filter Switch, with double IR-CUT filters, designed for special applications
Suitable for 1/2.5″ HD sensors (5MP)
Filters: 645nm IR CUT filter(Day) + AR filter(Night)
Metal/plastic Holder hole distance: 18mm, 20mm, 22mm optional
This product is suitable for high definition SDI/CVI cameras, high definition IP cameras, the pure analog cameras, consumer IP camera, door bellring cameras, vehicle cameras, etc. in CCTV surveillance industry. it can solve the problem of the camera image partial color in the daytime and infrared effect weak in the evening,etc.
IR CUT Removable module parameter
Filter effective area: 7.2*5.5mm
Operating environment: temperature -20~80℃
Currency: 20-100mA
Drive voltage: 1.5-5V or 2-5V
Driver: Motor
645nm IR filter Spec.
410~420nm≥80%
420~600nm avg. 90%,min. 80%
645±10nm 50%
715nm≤6%
735~1050nm≤2%
1051~1100nm≤4%
AR glass spec.
Wavelength 420~1100nm
pass rate T>97%
