Product Description

M12 mounted IR-Cut Filter Switch, with double IR-CUT filters, designed for special applications
Suitable for 1/2.5″ HD sensors (5MP)
Model: ICR513-M12
Filters: 645nm IR CUT filter(Day) + AR filter(Night)
Metal Holder hole distance: 18mm, 20mm, 22mm optional
This product is suitable for high definition SDI cameras, high definition IP cameras, the pure analog cameras, consumer IP camera, etc. in CCTV surveillance industry. it can solve the problem of the camera image partial color in the daytime and infrared effect weak in the evening,etc.

IR CUT Removable module parameter
Filter can use effective area: 7.2*5.5mm
Operating environment: temperature
Currency: 20-100mA
Drive voltage: 1.5-5V
Driver: Motor
